Micro Processor Glossmeter , Paper Microcomputer Glossmeter , Paper Testing Equipments
Usage:
HD-A823-1 is a portable fixed angle gloss meter, a meter, to test the gloss-ness of the paint, plastic, paper, ceramic, stone, wood, aluminum and alloy.
Features:
1). Light to carry, rotating calibration |
2). Small power, long-life light source, can test when opening |
3). Easy to operate, no need to zero. |
4). Precise, stable and reliable |
Standards
ISO2813,ASTM D1455,ASTM D523,ASTM D2457,JIS Z8741,GB9754,GB8807.
Specification:
Function | 65 lighting and CIE photo pic function |
photo metric linearity | 0.3% |
Measuring range | 75 ° angle gloss: 1 ~ 384 (gloss units) Gloss 45 ° angle: 1 ~ 1674 (gloss units) Gloss (20 °): 1 ~ 2037 (gloss units) |
Accuracy | 1 gloss units |
Repeatability | 0.5 gloss units |
Sample size | 50 mm (length) × 50 mm (width) |
Power supply | AC220V ± 10% 50Hz |
Working environment | temperature 5 ~ 40 ℃, relative humidity less than 85% |
Dimensions | 300 mm (length) × 380 mm (width) × 260 mm (height) |
Instrument Weight | ≤ 8.5kg |
Instrument Weight | ≤ 14.5kg |
